Product Code : SCL-CELE-14171
Overview
The Permeability / Fluidization Studies
Apparatus is a compact benchtop trainer designed for the
experimental study of flow characteristics through packed and fluidized beds
of granular materials. The unit allows observation of the pressure drop
across a bed, the onset of fluidization, and the verification of
Kozeny’s equation.
Constructed from non-corrosive and
transparent materials, the setup provides clear visualization of flow
patterns and air bubble formation. A precision flowmeter and differential
manometer ensure accurate measurement of flow rate and pressure drop. The
apparatus is ideal for laboratory demonstrations and practical studies in chemical,
civil, and environmental engineering.
A detailed Operation & Maintenance
Manual is supplied, enabling easy setup, operation, and experimental
analysis.
Key
Features
- Compact benchtop unit with
corrosion-resistant frame and fittings.
- Transparent test section and tubing for easy visualization of flow and bubble behavior.
- Constant head tank ensures
steady water flow and air release.
- Precision flowmeter and mercury manometer for accurate flow and pressure measurements.
- Needle control valve for
fine flow adjustment.
- Easily disassembled test section for
quick sample replacement and cleaning.
- Suitable for studying both permeability and fluidization
behavior of various media.
Technical
Specifications
|
Component |
Specification |
|
Sample Tube (Test Section) |
Inner Diameter: 38 mm; Length: 507 mm |
|
Flowmeter Range |
50 – 800 ml/min (Variable Area Flowmeter) |
|
Manometers Provided |
0.5 m Water Differential Manometer and 0.5 m Mercury Manometer |
|
Frame Material |
Steel tubing with epoxy coating for corrosion resistance |
|
Bed Medium |
Sand or other granular solids (user supplied) |
|
Constant Head Tank |
Non-corrosive construction with air release mechanism |
|
Valves |
Needle and isolation valves with air release feature |
|
Configuration |
Benchtop, self-contained unit |
Experimental
Capabilities
- Measurement of pressure drop
through packed beds.
- Verification of Kozeny’s equation for
laminar flow through porous media.
- Study of fluidization characteristics in a liquid fluidized
bed.
- Determination of bed permeability for
various granular solids.
- Attrition test on
particles under fluidization conditions.
Educational
Objectives
- Understand the relationship between flow rate, pressure drop,
and bed structure.
- Analyze Darcy’s Law and Ergun equation for packed
beds.
- Identify the critical velocity for fluidization.
- Investigate bed expansion and particle motion in fluidized
systems.
Required
Services
|
Service |
Specification |
|
Water Supply |
Tap water connection (constant flow) |
|
Drainage |
Required for recirculated water discharge |
Documentation
A comprehensive Operation & Maintenance
Manual is provided, containing:
- Detailed experimental procedures
- Theoretical background and equations
- Data recording templates and result analysis
- Maintenance and calibration guidelines
