Kaplan Turbine Test Setup Manufacturer,Supplier and Exporter in India

Product Code : SCL-CELE-14105

The Francis Turbine, a type of reaction turbine developed by Sir J.B. Francis, is a crucial machine in hydropower generation. It is classified as a mixed-flow turbine because water enters the runner radially through the outer periphery and exits axially. A defining characteristic is that as water flows through the runner, a portion of its pressure energy continuously converts to kinetic energy, meaning the runner is always under positive pressure. The runner is fully enclosed in an airtight casing that remains filled with water. This experimental setup is designed to study the performance of the Francis turbine, using a Centrifugal Pump to feed water radially to the runner. The unit includes a guide mechanism and a draught tube at the outlet. A brake arrangement (dynamometer) is connected to the shaft to apply a load, which is necessary for calculating power and efficiency.

Objectives: Francis Turbine Performance Study

Objective	Key Metric Investigated	Application in Hydraulic Power
To study the operation of a Francis Turbine	Flow Dynamics, Pressure-Energy Conversion	Understanding the mixed-flow and reaction principles of operation.
To determine the Output Power of Francis Turbine	Mechanical Power (Pout)	Quantifying the mechanical work output using the brake arrangement.
To determine the Turbine Efficiency	Hydraulic Efficiency	Calculating the ratio of output mechanical power to input hydraulic power.

Technical Features and Specifications: Francis Turbine Apparatus

Feature / Component	Parameter / Material / Function	Detail
Turbine Type	Francis Turbine	Mixed-Flow Reaction Turbine.
Flow Control	Guide Mechanism	Fitted to control the direction and flow rate of water entering the runner.
Runner Assembly	Mounting and Support	Directly mounted on a central SS shaft, supported by a thick cast iron pedestal.
Flow Observation	Turbine Casing	Circular window with transparent acrylic sheet for observation.
Energy Input Measurement	Gauges	Pressure and vacuum Gauges fitted at the Inlet and Outlet to measure total supply head.
Energy Output Measurement	Brake Arrangement	Fitted for load application and efficiency calculation.
Outlet Feature	Draught Tube	Fitted at the turbine outlet.
Feed System	Pump	Centrifugal Pump.
Utilities	Electricity Supply	15 kW, 440V AC, Three Phase.
