Product Code : SCL-CELE-14132
The Pump
Impeller Display Panel is an educational tool designed to familiarize
students with the various impeller geometries used in different types of
roto-dynamic and positive displacement pumps. Proper understanding of impellers
is crucial as their geometry dictates pump performance and is essential
for the design and selection of pumps.
The panel
consists of scaled models of pump impellers that highlight the key
differences between impellers used in various fluid machinery, including
centrifugal, axial, and mixed flow pumps.
Specifications
and Features
|
Component
/ Feature |
Parameter
/ Specification |
Detail
/ Value |
|
Product |
Name |
Pump
Impeller Display Panel |
|
Contents |
Quantity |
Impellers
of five different pumps (selected from a list of nine types). |
|
Mounting |
Type |
Designed
for desktop mounting. |
|
Panel
Dimensions |
Size |
550 mm x
350 mm. |
|
Weight |
Mass
(Approx.) |
18 kg. |
|
Objective |
Focus |
Familiarize
students with impellers of roto-dynamic and positive displacement pumps. |
Impeller
Types for Display (Any Five)
The panel
can include any five of the following impeller types, categorized by pump type:
|
Pump
Category |
Impeller
Type Examples |
|
Centrifugal |
Forward
curved, Backward curved, Radial tipped, Airfoil bladed, Open type, or with
shrouds. |
|
Roto-dynamic |
Axial
flow pump impeller. |
|
Roto-dynamic |
Mixed
flow pump impeller. |
|
Positive
Displacement |
Vane
pump impeller. |
|
Positive
Displacement |
Gear
pump impeller. |
