Product Code : SCL-CELE-14084

This set of experiments focuses on core principles of aerodynamics and fluid-structure interaction, typically conducted within a wind tunnel or similar flow bench apparatus. The primary goal is the empirical determination of forces and flow characteristics essential for designing efficient flying vehicles and structures. The analysis moves beyond simple force measurement to include detailed studies of the flow field, specifically focusing on the pressure variations over body surfaces, the nature of the boundary layer, and the structure of the wake downstream of the object. Furthermore, the inclusion of flow visualization techniques, particularly in conjunction with a fog generator, allows for the direct observation of streamlines, which is crucial for understanding complex unsteady phenomena like flutter.

Objectives: Aerodynamic Measurement and Flow Field Characterization

Objective	Key Metric / Phenomenon	Application in Aerodynamics
Determine Drag and Lift Coefficients for Different Models	Coefficients CD and CL	Fundamental quantification of forces for aircraft and vehicle design.
Pressure Distribution on Bodies Immersed in a Flow	Static Pressure p(x, y)	Measuring surface pressure to calculate lift, drag, and moment distributions.
Boundary Layer Analysis	Boundary Layer Thickness (delta), Separation Point	Empirical study of the thin layer near the surface where viscosity effects are dominant.
Investigation of Flutter	Aeroelastic Instability	Analyzing the self-excited, sustained oscillation of an object due to aerodynamic forces.
Wake Measurement	Velocity Deficit, Turbulence	Characterizing the turbulent region downstream to calculate drag indirectly and understand mixing.
In Conjunction with the Fog Generator	Streamline Visualization	Using smoke or fog to make instantaneous flow paths visible for qualitative analysis.
Visualization of Streamlines	Flow Patterns	Direct observation of flow separation, reattachment, and vortex shedding .
