Transistor Characteristics Apparatus (Socket Type) Manufacturer,Supplier and Exporter in India
 (1).jpg)
Product Code : SCL-EAE-14657
The Transistor Characteristics Apparatus (Socket Type) enables students to analyze input, output, and transfer characteristics of transistors in CE (Common Emitter) and CB (Common Base) configurations.
The socket arrangement allows quick transistor replacement without soldering, making it perfect for repeated laboratory use.
Key Features
- Socket-based transistor insertion for fast, safe, and solder-free connections
- Supports NPN & PNP transistors
- Complete built-in regulated DC power supply
- Digital meters for accurate measurement of voltage and current
- Designed for studying:
- Input characteristics (IB vs VBE)
- Output characteristics (IC vs VCE)
- Transfer characteristics
- Highly stable signal and power conditioning
- Compact, durable and classroom-friendly
- Clear front-panel labelling for student learning
- Overload protection for safe operation
Technical Specifications
|
Parameter |
Specification |
|
Transistor Type |
NPN & PNP (Socket Type) |
|
Configuration Supported |
CE & CB |
|
Power Supply |
Built-in regulated DC power supply (0–30V depending on model) |
|
Digital Meters |
DC Voltmeter & DC Ammeter (High accuracy) |
|
Base Current Control |
Variable through potentiometer |
|
Collector Supply Control |
Continuously variable |
|
Indicators |
Power ON/OFF LED |
|
Protection |
Current-limited & overload protection |
|
Panel |
High-quality printed front panel with clear circuit diagram |
|
Enclosure |
Powder-coated metal cabinet |
Applications
- Engineering Colleges
- Polytechnic Institutes
- B.Sc. / M.Sc. Physics Labs
- Electronics Training Labs
- TVET / ITI Workshops
Why Choose Indian Lab Supplier for This Product?
Indian Lab Supplier uses high-grade components ensuring long life, accuracy, and reliable performance.
All instruments meet educational, engineering, and industrial training standards.
We provide model variations (with extra meters, advanced features, different ranges, etc.) based on institutional needs.
Direct manufacturer pricing ensures the best value for schools, colleges, and training centers.
Availability of spare parts, repairs, and training support for long-term usability.
Fast dispatch and safe packaging for all states.
