Air Compressor- LD & HD Manufacturer,Supplier and Exporter in India
.png)
Product Code : SCL-SH-12013
Indian Lab Suppliers supplies the Air Compressor - LD & HD (Product ID: 12013), listed within the Sanitation & Hygiene range under Water and Sanitation equipment. This is a workshop-grade rotary air compressor available in two power ratings, not itself a sanitation or hygiene item.
Quick Answer
The Air Compressor - LD & HD is a belt-free, direct-drive rotary screw compressor supplied in two models — the 5hp/3.7kW ATS 05 RD 22 and the 7.5hp/5.6kW ATS 07 RD 22 — both running at 960rpm up to 12 bar/175psi, used to supply compressed air for garage and workshop tools such as tyre changers, pneumatic lifts and spray equipment.
Key Specifications
| Parameter | ATS 05 RD 22 (LD) | ATS 07 RD 22 (HD) |
|---|---|---|
| Product ID | 12013 | |
| Power | 5hp / 3.7kW | 7.5hp / 5.6kW |
| Compressor speed | 960rpm | 960rpm |
| Max. working pressure | 12 bar / 175psi | 12 bar / 175psi |
| Free air delivery | 15.5cfm | 24cfm |
| Air receiver | 220 | 220 |
| Overall dimensions (L x W x H) | 1,590 x 595 x 1,045mm | 1,640 x 635 x 1,110mm |
| Weight | 190kg | 255kg |
Both models use an integrated drive with a compact top block design and larger aluminium inter- and after-coolers, giving 32% more heat transfer area than a comparable belt-drive unit; the manufacturer also states 57% lower oil consumption and a 12% smaller footprint versus belt-drive alternatives, with low noise levels in operation. On the duplex configuration, each top block can run independently to match varying air demand.
Where This Compressor Is Used
The Air Compressor - LD & HD supplies the compressed air that pneumatic garage equipment runs on, and is typically installed alongside vehicle-servicing equipment such as the Four Post Lift, where air tools and lift controls both draw from a common compressed-air line.
Why Buy from Indian Lab Suppliers
Indian Lab Suppliers is an India-based equipment manufacturer and exporter supplying the Air Compressor - LD & HD alongside its broader Water and Sanitation catalog, with documentation such as a Certificate of Origin available on request for institutional and export orders.
Frequently Asked Questions
What is the difference between the LD and HD models?
The LD model (ATS 05 RD 22) is rated at 5hp/3.7kW with 15.5cfm free air delivery; the HD model (ATS 07 RD 22) is rated at 7.5hp/5.6kW with 24cfm free air delivery. Both run at 960rpm up to 12 bar/175psi.
What is the maximum working pressure?
12 bar (175psi) on both models.
How much less oil does it use than a belt-drive compressor?
The manufacturer states 57% less oil consumption compared to belt-drive units.
Can the duplex configuration run each block independently?
Yes — on the duplex model, each top block can be run independently based on air demand.
Do you supply this equipment for institutional or export orders outside India?
Yes. Indian Lab Suppliers quotes equipment for institutional and tender buyers across export markets — see the Tenders page for documentation requirements.
Related Categories
Sanitation & Hygiene · Water and Sanitation · Water Testing · Pump Riser Pipe · Water Treatment
Request a Quote
For pricing, bulk quantities or tender documentation on the Air Compressor - LD & HD, reach our team via Contact Us or submit your requirement through our Tenders page.
